GE 9 Graphic Equalizer

The Ibanez GE 9 Graphic Equalizer is a vintage analog pedal known for its exceptional equalization capabilities. This pedal was manufactured in Japan and is highly sought after by musicians and collectors. The technical specifications for the GE 9 Graphic Equalizer are as follows:

- Input Impedance: 500K ohms
- Output Impedance: <1K ohms
- Maximum Input Level: +10 dBm
- Maximum Output Level: +5 dBm
- Filter Bandwidth: 1 octave
- Filter Control Range: +/- 15 dB center detented
- Level Control Range: +/- 15 dB center detented
- Equivalent Input Noise: -100 dBm (IHF-A)

The GE 9 Graphic Equalizer utilizes six octave-wide minimum-phase-shift filters, allowing for 15dB of boost or cut. The Level slider enables adjustment of the signal level without affecting the filter settings, making it a versatile addition to any musician's setup.
