Distorter

The Moollon Distorter is a high-quality effects pedal designed to deliver a thick and straight distortion sound with natural harmonics, reminiscent of the sound produced by cranked-up tube/non-master volume amplifiers from the 1950s and 1960s. The pedal features the following technical specifications:

- Moollon GW 109S Buffer Circuit inside
- Input Impedance: High 1M
- Output Impedance: Low 10k
- Maximum Output: 0dBm
- Maximum Gain: +42dB
- Current Draw: 13.5 mA (DC 9V)
- Controls: Volume, Tone, Dist
- In/Output Jacks: Switchcraft
- Foot Switch: Heavy Duty 3dpt
- Power Supply: 9 Volt Battery or DC Jack
- Dimensions: 110 x 60 x 45mm

The Distorter's Dist, Volume, and Tone controls interact organically, resulting in an increase in treble as the distortion becomes dirtier, replicating the characteristic behavior of tube amps. Additionally, the Moollon GW 109S Buffer Circuit minimizes ground noise, electrostatic noise, and mechanical noise from the switch by transforming the input signal into a low impedance output signal.

The pedal is suitable for use in various musical applications where a rich, powerful distortion effect is desired. It offers musicians the ability to achieve the distinctive sound of a cranked-up tube amp even at low volume levels, making it a versatile tool for both studio recording and live performances.
