Prophesy II

The Rocktron Prophesy II is a versatile guitar preamp and effects processor designed to provide a wide range of tonal options and effects for guitarists. Here are the technical specifications and features of the Prophesy II:

Specifications:
- Input impedance: 470K ohms
- Output impedance: <150 ohms
- Maximum input/output level: +20dBu
- MIDI in: 7-pin DIN
- MIDI out/thru: 5-pin DIN
- Input jack: 1/4" mono
- Output jacks: 1/4" left and right
- Recording output jacks: XLR left and right
- Power requirements: 9VAC / 3.4 amps
- Dimensions: 19" x 3.5" x 8"
- UL, CSA, and CE approved operation

Features:
- Dynamic Tube Replication Technology (DTR)
- User Definable Effect Configurations
- User Assignable Stereo Effect Loop
- Tap Tempo Delay and Tremolo
- Built-in Chromatic Tuner
- Stereo XLR Outputs
- Real Amp Knobs for On-The-Fly Tone, Volume, and Preset Adjustments
- "Pluck Detector" (patent-pending) and ADSR for Dynamic Effect Control
- Pre and Post Distortion and Global EQ
- Pre Distortion Effects and Post Distortion Effects
- Programmable Speaker Simulator with Parameters for Speaker Size, MIC Position, Reactance

Preamp Section:
- Four channels with distinct "voicings" to provide a variety of desired tube amp sounds
- Parametric Pre EQ for tone shaping
- Parametric Post EQ for additional tone adjustments
- Global Parametric EQ for overall output adjustment

Effects Section:
- Pre-effects section includes Wah, Compressor, HUSH(r), Pre-EQ, and one assignable effect
- Post-effects section provides ultra-transparent, high-quality effects with four assignable "effect blocks" for flexible configurations
- True stereo effect loop for external effects integration
- ADSR function with Rocktron's Pluck Detection for dynamic control

The Prophesy II offers a comprehensive set of features and technical specifications to meet the needs of guitarists seeking a powerful and flexible preamp and effects processor for stage and studio use.
