ZOIA

The ZOIA by Empress Effects is a modular synthesizer in pedal form, offering a wide range of features and functionalities. Here are the technical specifications and details:

- Pedal Type: Multi-FX
- Analog/Digital: Digital
- Presets: 64 x user presets
- Number of Effects: Over 50 ready-made effects modules
- Effects Types: Includes reverbs, delays, chorus', flangers, overdrives, and more
- Power consumption: 9V DC center negative, 300 mA
- Dimensions: H: 6.8 cm (including knobs), W: 14.4 cm, D: 9.4 cm
- Weight: 537 g
- Input Impedance: >= 1MΩ
- Output Impedance: 100Ω
- Frequency Response (-3dB): 10Hz – 23.4kHz
- Total Harmonic Distortion: 0.22%
- Dynamic Range: 105.5 dBA
- Input Headroom: +0.5 dBu (no pad), +5.7 dBu (6dB pad), +10.8 dBu (12dB pad)
- Output Headroom: +16.2dBu
- Power Input Connector: 2.1mm Barrel Connector
- Power Input Voltage: 9V DC (center negative)
- High-Quality Audio: 48kHz sampling, 24-bit conversion, and 32-bit internal processing
- Low-Noise Signal Path: Signal to noise of >105dB

The ZOIA comes with 80+ modules and growing, allowing users to create their own effects, synths, control devices, and more. It also features an OLED display screen for easy editing, control port and MIDI connectivity, customizable patch recall system, built-in help function, and an SD card for patch storage and firmware updates.

Additionally, the ZOIA offers a dedicated community for users to swap and share patches, providing a platform for continuous expansion and creativity.
