Twin-Lazers

The Twin-Lazers by Mr. Black is a true-stereo phase-shifter effect pedal featuring fully isolated left and right channel audio paths. It offers two fully-independent 4-stage or 6-stage phase-shifters, which can be run independently in stereo or chained together via a standard patch cable to double the stages for series-mono 8-stage or extra syrupy 12-stages of phase- shifting swirl.

Key Features:
- Three simple controls: Mix (phase shift mix/level), Shift (phase oscillator 1 & 2 phase lag; 0° - 180° phase lag between oscillators), and Rate (master oscillator rate).
- Two modes of operation: Four-Stage (four-stages of phase shift per channel) and Six-Stage (six-stages of phase shift per channel).
- Wide range of oscillator speeds (5Hz - 0.2Hz) and optional tap-tempo input with up to 12.5-second (0.08Hz) cycle.
- Intuitive and easy to use preset/favorite-setting with a Save push-button and Preset foot-switch.
- Expression control input, assignable to any control knob on-the-fly.
- Bi-Color Indicator/Status LED, Bi-Color Mode indicator LED, and Bi-Color Preset indicator LED.
- Buffered-Bypass.

Technical Specifications:
- Input Impedance: ~500KΩ (each channel)
- Output Impedance: ~2KΩ (each channel)
- 9VDC 2.1mm negative center-pin power
- <70mA Current Draw
- Product dimensions: 3.97"W x 4.72"L x 2"H (101MM x 120MM x 51MM)
- Weight: 16 oz (454g)

The pedal is designed for use in a true-stereo signal chain or in a mono signal chain. It offers a versatile range of phase tones and is handmade with a focus on ease of use.
