XYZ Waves

The Foxgear XYZ Waves is a dedicated platform for modulation algorithms, offering five modulation algorithms for guitarists and bass players. It features three multifunction controls that provide unprecedented control and versatility in a super compact size pedal. The XYZ Waves is true bypass, with a 100% analog signal path, preserving the original tone without converting the signal to digital.

The pedal's dimensions are 2.3” x 4.7” x 1.2” (6cm x 12cm x 3cm) and it requires a power input of 9 to 12VDC with negative tip polarity. The power consumption at 9V is approximately 70mA. The input impedance is less than or equal to 1M Ohm, and the output impedance is less than or equal to 10K Ohm. The pedal weighs 0.2kg (0.4lbs).

The XYZ Waves includes conventional modulation algorithms such as chorus, phase, and tremolo, coupled with a reverb. Additionally, it offers unconventional algorithms like envelope filter and polypitch, expanding creativity and sound possibilities. The pedal provides the facility and sound quality of larger and more expensive multi-effect units in a pedalboard- friendly size.

The warranty for Foxgear products covers 5 years from the date of purchase and includes specific terms and conditions for warranty claims.
