Tone Garage Trike Fuzz

The Vox Tone Garage Trike Fuzz is an octave fuzz pedal designed with vintage character and specially selected diodes. It offers a range of one octave up and two octaves down, with three types of octave settings: +1 or, -1 and -2, or all upward and downward octaves to achieve thick vintage fuzz sounds. The pedal features a tone control for +1 octave and a volume control for -2 octave.

Specifications:
- Input impedance: 680kΩ
- Output impedance: 2.2kΩ
- Connections: INPUT jack (guitar input), OUTPUT jack (line output)
- Power: AA battery x 6 / AC adapter / DC 9V (Option)
- Consumption current: 14mA
- Battery Life: Approximately 280 hours
- Dimensions: 87 x 132 x 63 mm / 3.43 x 5.20 x 2.48 inches
- Weight: 420 g / 14.81 oz (not including battery)

The pedal operates the downward octave circuits in series and combines them in parallel with the upward octave at the end, allowing for a diverse range of sounds not typically obtained with existing octave fuzz units. Additionally, the Trike Fuzz features true-bypass switching for pure tone and a rugged aluminum die-cast body designed to withstand the rigors of the road.
