SpaceTime

The Vahlbruch SpaceTime is a handmade echo pedal that combines the advantages of analog and digital circuits in a unique way. It offers a warm and deep sounding delay pedal, easy to operate, and capable of creating beloved analog delay typical self-oscillations. The pedal features the following specifications:

- Unique MagTraB switching technology
- Internal switch for "true bypass" or "buffered bypass"
- Controls for Time, Repeats, and Mix-Level
- Tone-Switch for bright, mellow, and dark
- Analog dry path with a perfectly flat frequency response
- Low noise circuit design
- Maximum delay time of 660 ms
- Input impedance: 1M Ohms
- Output impedance: 1k Ohms
- Current consumption: 60mA
- Requires an external regulated 9V power supply (not included), polarity: positive@ring / negative@tip
- Dimensions: 115mm x 70mm x 48mm
- Weight: 240g
- Handmade in Germany

The SpaceTime pedal is equipped with the unique "MagTraB" switching technology, which offers smooth and silent switching without mechanical switch clicks. Additionally, it allows users to choose if the pedal powers up in "on" or "bypass" state. The pedal also features an internal DIP-switch for state selection.
