Brick Drive BDI-1

The Providence Brick Drive BDI-1 is a bass preamp pedal designed to deliver high-quality sound and versatile functionality. Here are the technical specifications and features:

- Employs Vitalizer B circuit in the input section, which converts high impedance signals to low impedance signals, minimizing degradation of sound quality and delivering natural, faithful instrument sound.
- The Vitalizer B circuit tightens up the bottom end, providing more vivid and clear sound compared to other processors and effects.
- Internal operating voltage boosted to 21V for increased dynamic range and low noise.
- Mix control allows blending of drive sound and clean sound through the preamp EQ, adding nuance to the overdriven sound.
- EQ section based on the Dual Bass Station's circuit, featuring controls for Treble, Mid, Bass, and Presence for precise tone shaping.
- Loaded with a balanced XLR DI out for flexibility in both live and recording environments, with a ground lift switch to prevent ground loop noise.
- Bypass/Mute switch for selecting the mode when the pedal is bypassed, offering direct sound bypassing the Vitalizer B circuit or mute mode for instrument switching or tuning.
- Controls: CLEAN LEVEL, DRIVE LEVEL, MIX, DRIVE GAIN, BASS, MID, MID FREQ, TREBLE, PRESENCE, BYPASS/MUTE MODE SW, BYPASS/MUTE-OFF SW, CLEAN-DRIVE SW, GND LIFT SW
- Connectors: Standard 1/4-inch Phone JACK (IN, OUT, VZ THRU), XLR TYPE (DI OUT), DC12V INPUT
- Power consumption: DC12V 80mA (Power supply NOT included)
- Size: 125(D) X 97(W) X 50(H)mm
- Weight: Approx. 380g
